MORSO UP-M Hydraulic Stapler

NOTE: Prices are approximate and subject to negotiation.

A fully mechanical machine for joining wooden corner pieces. It is operated by a foot pedal: first, the two pieces to be joined are locked in place horizontally and vertically, and then a staple is driven in. By pressing the pedal halfway, i.e., only partially, staples can be driven in one after another (necessary for deeper, more contoured models) without unlocking the corner. The JOINT 5x5 MEC stapler can use PILM staples in sizes 7/10/12 mm. It joins strips at angles of 90°, 120°, and 135°, with minimum dimensions of 5x5 and maximum dimensions of 100x70. The stapler is equipped with two types of vertical clamps, allowing the clamp shape to be well-adjusted to the frame’s shape, as well as washers for the angle stop to improve the support of the frame corner. It can be operated from both the front and the back. The standard operating position is from the front.
Additional equipment: Hex/octagon
angle reducers;
Replaceable 40-gauge clamp with felt; Filler
inserts for 4 mm and 12 mm staples;
Extension arms;
Pads for the angle stop; Flexible
halogen lamp.

Cross-section of the strip being cut - min 5x5mm; max 100x70mm
Dimensions - 55 x 38 x h115cm
Weight - 44kg

Available additional equipment:
- halogen
lamp -
120° angle bracket -
135° angle bracket - 7
mm guide rail riser - staple height
compensators - flat angle clamp with rubber
- arms
